Getting started with Python

Django Javascript Python Node.js / Next.js / React

The Shellviz Python library provides powerful data visualization capabilities for Python scripts and applications. It creates a local web server that can receive and visualize data, making it perfect for data analysis, debugging, and monitoring applications.

Installation

Install Shellviz with pip:

pip install shellviz

Note:

Are you using Django? Check out the dedicated Django Integration guide for specific features.

Send data to Shellviz

The easiest way to initialize Shellviz is importing and calling any of the visualization methods directly:

from shellviz import log, json
log('hello world')
# Shellviz serving on http://192.168.86.124:5544
json({'type': 'fruit', 'name': 'pear'})

The first method call to Shellviz will initialize a global instance that will output connection data. You can also start the Shellviz server manually if you would like additional control.

from shellviz import table
table([['cell 1.1','cell 1.2'],['cell 2.1', 'cell 2.2']])

There are many different visualization options available. For a full list, check out the visualizations documentation.

Launch Shellviz

Open Shellviz by pointing your browser to the URL printed in your console (127.0.0.1:5544 by default). You should see your Shellviz instance instance running in front of you (if not, check out our troubleshooting guide).

You can also embed a widget version of Shellviz on your site that lives on the bottom right of your page. Try clicking the "Run" button on the above code - it should launch in the widget.

Quick Start

Basic Usage

from shellviz import log, table, json

# Start logging data
log('my first shellviz command')
# Shellviz serving on http://127.0.0.1:5544

# Display tabular data
table([("Alice", 25, 5.6), ("Bob", 30, 5.9), ("Charlie", 22, 5.7)])

# Show JSON data
json({"name": "Alice", "age": 25, "height": 5.6})

Custom Instance

from shellviz import Shellviz

# Create custom instance
sv = Shellviz(port=3333, show_url=False)
sv.log('Custom instance message')
sv.table([('Name', 'Value'), ('Custom', 123)])

Configuration

Available Options

SHELLVIZ_PORT - Port number (default: 5544)
SHELLVIZ_SHOW_URL - Show URL on startup (default: True)
SHELLVIZ_URL - Custom server URL (overrides port-based URL)

Shellviz can either be configured by specifying configuration during initialization:

from shellviz import Shellviz
sv = Shellviz(port=9000, show_url=False, url="https://my-server.com")

Alternatively, you can set configuration via environment variables:

export SHELLVIZ_PORT=8080

Examples

Performance Dashboard

import psutil
import time
from shellviz import progress, pie, log

while True:
    # System metrics
    progress(psutil.cpu_percent(), id='cpu_usage')
    progress(psutil.virtual_memory().percent, id='memory_usage')

    # Disk usage by partition
    disk_data = []
    for partition in psutil.disk_partitions():
        try:
            usage = psutil.disk_usage(partition.mountpoint)
            disk_data.append({
                'name': partition.device,
                'value': usage.percent
            })
        except PermissionError:
            continue

    pie(disk_data, id='disk_usage')
    log(f'System check at {time.strftime("%H:%M:%S")}', id='monitoring')

    time.sleep(5)

Dashboard

API Response Analysis

import requests
from shellviz import json, table, card

response = requests.get('https://api.example.com/users')
data = response.json()

# Show raw response
json(data, id='api_response')

# Extract and show user table
if 'users' in data:
    user_table = []
    for user in data['users']:
        user_table.append([user['name'], user['email'], user['created_at']])

    table([['Name', 'Email', 'Created']] + user_table, id='users')

# Show summary stats
card({
    'total_users': len(data.get('users', [])),
    'response_time': f'{response.elapsed.total_seconds():.2f}s',
    'status_code': response.status_code
}, id='summary')
